Motor, Baldor 3450RPM 0.5HP Hazardous - $300 (Hilton)
condition:
new
make / manufacturer:
Baldor Motors
model name / number:
34-7056-5719
size / dimensions:
3450 RPM Hazardous Motor
QR Code Link to This Post
No. C12314701
0.5 HP
Spec 34-7056-5719
NEW, open Box
T Code T3C
UL Listed
Electric Motor for Hazardous Locations
Class I Group D
Class II Group F and G
Class I Zone I Group – IIA
Volts 115/230
Amps 7.4 / 3.7
R.P.M. 3450
HZ 60
PH 1 Class B
SER F 1.00
DES N CODE K
Rating 40C AMB-CONT
FRAME 56CZ
NEMA NOM EFF 57%
Usable at 208V A PF 70%
Thermally Protected
Caution: Motor May Automatically Restart
Baldor Electric Co.
Ft. Smith AR USA
NP0016XPSL
Enclosure XPFC
Frame 56CZ
Frame Material Steel
Frequency 60.00 Hz
Motor Letter Type Cap Start, Induction Run
Output @ Frequency .500 HP @ 60 HZ
Phase 1
Synchronous Speed @ Frequency 3600 RPM @ 60 HZ
Voltage @ Frequency 230.0 V @ 60 HZ
115.0 V @ 60 HZ
XP Class and Group CLI GP D; CLII GP F,G
XP Division Division I
Agency Approvals CSA UL
Ambient Temperature 40 C
Auxillary Box No Auxillary Box
Auxillary Box Lead Termination None
Base Indicator Rigid
Bearing Grease Type Polyrex EM (-20F +300F)
Blower None
Current @ Voltage 7.400 A @ 115.0 V
3.700 A @ 230.0 V
Design Code N
Drip Cover No Drip Cover
Duty Rating CONT
Efficiency @ 100% Load 57.0 %
Electrically Isolated Bearing Not Electrically Isolated
Feedback Device NO FEEDBACK
High Voltage Full Load Amps 3.7 a
Front Face Code Standard
Front Shaft Indicator None
Heater Indicator No Heater
Insulation Class B
Inverter Code Not Inverter
IP Rating NONE
KVA Code K
Lifting Lugs No Lifting Lugs
Locked Bearing Indicator No Locked Bearing
Motor Lead Exit Ko Box
Motor Lead Termination Flying Leads
Motor Lead Quantity/Wire Size 6 @ 18 AWG
Motor Type X3416L
Mounting Arrangement F1
Number of Poles 2
Overall Length 13.22 IN
Power Factor 71
Product Family Hazardous Location Motor
Pulley End Bearing Type Ball
Pulley Face Code C-Face
Pulley Shaft Indicator Special Combination
Service Factor 1.00
Shaft Diameter 0.625 IN
Shaft Extension Location Pulley End
Shaft Ground Indicator No Shaft Grounding
Shaft Rotation Reversible
Shaft Slinger Indicator No Slinger
Speed 3450 rpm
Speed Code Single Speed
Motor Standards NEMA
Starting Method Direct on line
Thermal Device – Bearing None
Thermal Device – Winding None
Vibration Sensor Indicator No Vibration Sensor
Winding Thermal 1 Automatic Thermal Overload
Winding Thermal 1 Location EP
XP Temp Code T3C
~~~~~~~~~~~~~~~~~~~~~~~~~
TheClearanceMan
30lbs, 12 x 17 x 11
