ATI Fire GL4 4x AGP Pro Video Card - Dual DVI - $10 (Chili)
condition:
excellent
make / manufacturer:
ATI
model name / number:
Fire GL4
size / dimensions:
9 x 4 x 1.5 inch
QR Code Link to This Post
Specifications:
(PC Pict CL)
Bus type: AGP Pro 2X/4X v2.0 Compliant w/ Side Banding
Memory: 128 Mb DDR SGRAM, Unified Framebuffer
3D performance: 29 million Triangles/second, G-Shaded, Z-buffered, non-Textured
33 Million Anti-Aliased Vectors/second
512 Million Pixels/second fill rate, G-Shaded, Z-buffered, non-Textured
250 Million Pixels/second Trilinear Texture fill rate (Mip-mapped)
Connectors: Two DVI-I Digital Monitor Output
StereoGraphics Connectors
RAMDAC: 300 MHz / 30-bit Palette DAC
Form factor: Single, Full Length AGP/Pro50 Card Length
AGP compatible: Full AGP 2X/AGP 4X support (up to 1GB/s bandwidth)
VESA: VBE 2.0 (super VGA modes)
DPMS energy saving
DDC-2b support for plug and play detection of monitor
28130070-004 ATI 128Mb AGP Fire GL4 Video Adapter
General
Interface Type AGP 4x
Max Monitors Supported 2 Interfaces
2 - 24+5 pin combined DVI - female
1 - 3 pin mini-DIN - female
Graphics Engine
IBM RC1000
2D/3D Graphics Coprocessor / Vendor
IBM GT1000
Bus Type API Supported
OpenGL, DirectX, Direct3D
RAMDAC 300 MHz
Manufacturer
ATI Technologies Inc.
Memory Size 128 MB / 128 MB (max)
Technology DDR SGRAM
Power Device
Type none
Interface Provided
Gender female
Connector Qty
1, 2
Type
display / video
Interface
DVI-Analog/Digital, stereo video sync-out
Qty
1, 2
Connector Type
24+5 pin combined DVI, 3 pin mini-DIN
Video
Video Output multi-monitor graphics card
Graphics Processor IBM RC1000
Colors Max Resolution (external) 32-bit color
Type
none
Video Output
Colors Max Resolution (external) 32-bit color
Fill Rate (pixels) 512 million pixels/sec
Fill Rate (triangles) 29 million triangles/sec
Fill Rate (texels) 250 million texels/sec
Type graphics card
Interface Type AGP 4x
Graphics Processor Manufacturer
other
Graphics Processor
IBM RC1000
RAMDAC Clock Speed
300 Hz
Max Monitors Supported 2
Max External Resolution 1920 x 1200
V-Sync Rate at Max Res. (external) 75 Hz
API Supported Direct3D, DirectX, OpenGL
Analog Video Format none
Supported Video Signal DVI
Analog Video Signal none
Digital Video Standard
Digital Visual Interface (DVI)
System Requirements
OS Required Linux, Microsoft Windows 2000 / NT4.0
Header Brand ATI
Product Line ATI FIRE
Model GL4
Packaged Quantity 1
Compatibility PC
Interface Required
Type none
Video Memory Technology DDR SGRAM
Installed Size 128 MB
Software Type Drivers & Utilities
Slot Required Type AGP
Total Qty 1
General
Manufacturer ATI Technologies Inc.
